Square Glass Spigot – overview
The Square Glass Spigot (MOD 6100) holds a frameless glass panel on a 48 mm square post with a 104 × 104 mm base plate. Its clamp is 100 mm high, as shown in the catalogue drawing.
MOD 6100 is listed on page 20 of the UNIKIM 2024 catalogue in three heights. It is also available in matte black – the Black Glass Spigot (MOD 6100) – and as MOD 6101 with a two-bolt clamp, the Stainless Steel Glass Spigot (MOD 6101).
Every UNIKIM glass spigot is made in AISI 316 stainless steel (Art. No. prefix A4), the grade for swimming pools, terraces and coastal sites.
Specifications
| Model | MOD 6100 (catalogue p. 20) |
| Shape | Square post 48 mm on 104 × 104 mm base plate |
| Height H | 150, 160 or 180 mm |
| Clamp | 100 mm high (drawing) |
| Material | AISI 316 stainless steel (A4) – suitable for pools and coastal sites |
| Finish | Brushed (satin); matte black on request |
Versions and article numbers
| Art. No. (AISI 316) | Height H |
|---|---|
| A4.6100.01.S | 150 mm |
| A4.6100.02.S | 160 mm |
| A4.6100.03.S | 180 mm |
Applications
Frameless glass pool fences, roof terraces, balconies and stair landings with straight, modern lines; residential and commercial projects.
Installation notes
- Fix the base to a concrete slab or a structural sub-floor with anchors chosen by your engineer.
- Use rubber inserts sized to your glass, set the panel height and tighten the clamping screws evenly.
- Check spigot spacing, glass type and loads against your local pool-fence or balustrade rules.
MOD 6100 or MOD 6101?
Both are square with the same base. MOD 6100 uses one clamping zone; MOD 6101 closes the clamp with two bolts. For a black finish choose the Black Glass Spigot (MOD 6100).
Why order from UNIKIM
We manufacture railing hardware in our own factory in Ningbo and supply distributors, contractors and fabricators worldwide. Mixed orders of spigots, slot tube, fittings and rubber can be shipped together, with OEM packing on request. Browse all glass spigots.
Related products
- Stainless Steel Glass Spigot (MOD 6101)
- Black Glass Spigot (MOD 6100)
- Round Glass Spigot (MOD 6000)
- Side Mount Glass Spigot 228 mm (MOD 6500)
FAQ
What is a square glass spigot?
A square stainless steel post on a base plate that holds a frameless glass panel from below. MOD 6100 has a 48 mm post on a 104 × 104 mm base.
Which heights are available?
150 mm (A4.6100.01.S), 160 mm (A4.6100.02.S) and 180 mm (A4.6100.03.S).
Is a black version available?
Yes – the same spigot in matte black: Black Glass Spigot (MOD 6100, finish B).
Is it suitable for pools?
Yes, it is made in AISI 316 stainless steel.
Need a price? Request a quotation with the model number, size, quantity and finish.
