Round Pool Fence Spigot, Two-Bolt Clamp – overview
The Round Pool Fence Spigot (MOD 6001) has the same Ø48 mm post and Ø103 mm base as MOD 6000, but its 100 mm clamp is closed with two bolts (at 30 mm and 40 mm in the catalogue drawing) for a strong, even grip on the glass.
MOD 6001 is listed on pages 21–22 of the UNIKIM 2024 catalogue in three heights. The set-screw version is the Round Glass Spigot (MOD 6000).
Every UNIKIM glass spigot is made in AISI 316 stainless steel (Art. No. prefix A4), the grade for swimming pools, terraces and coastal sites.
Specifications
| Model | MOD 6001 (catalogue p. 21–22) |
| Shape | Round post Ø48 mm on Ø103 mm base plate |
| Height H | 150, 160 or 180 mm |
| Clamp | 100 mm high, two bolts (drawing) |
| Material | AISI 316 stainless steel (A4) – suitable for pools and coastal sites |
| Finish | Brushed (satin) |
Versions and article numbers
| Art. No. (AISI 316, brushed) | Height H |
|---|---|
| A4.6001.01.S | 150 mm |
| A4.6001.02.S | 160 mm |
| A4.6001.03.S | 180 mm |
Applications
Frameless glass pool fences, spa and hotel pools, terraces and balconies with a round-spigot design.
Installation notes
- Fix the base to a concrete slab or a structural sub-floor with anchors chosen by your engineer.
- Use rubber inserts sized to your glass, set the panel height and tighten the clamping screws evenly.
- Check spigot spacing, glass type and loads against your local pool-fence or balustrade rules.
MOD 6001 or MOD 6000?
Both have the same round post and base. MOD 6001 clamps the glass with two bolts, the Round Glass Spigot (MOD 6000) (MOD 6000) with set screws from one side. Tell us your glass and we confirm the right clamp.
Why order from UNIKIM
We manufacture railing hardware in our own factory in Ningbo and supply distributors, contractors and fabricators worldwide. Mixed orders of spigots, slot tube, fittings and rubber can be shipped together, with OEM packing on request. Browse all glass spigots.
Related products
- Round Glass Spigot (MOD 6000)
- Stainless Steel Glass Spigot (MOD 6101)
- Square Glass Spigot (MOD 6100)
- Side Mount Fence Spigot 143 mm (MOD 6510)
FAQ
What is the difference between MOD 6001 and MOD 6000?
The post and base are the same. MOD 6001 has a two-bolt clamp; MOD 6000 uses set screws from one side.
Which heights are available?
150 mm (A4.6001.01.S), 160 mm (A4.6001.02.S) and 180 mm (A4.6001.03.S).
Is it suitable for salt-water pools?
It is made in AISI 316, the grade for pools and coastal sites; rinse it regularly with fresh water for the best finish.
Which glass do I need?
Toughened or laminated safety glass as required by your local pool-fence rules; we supply rubber for your glass build-up.
Need a price? Request a quotation with the model number, size, quantity and finish.
