Slot Tube Wall End Fitting (MOD 1172)
The Slot Tube Wall End Fitting (MOD 1172) has the same 37 × 30 mm square block as MOD 1171, mirrored, so both ends of a handrail between two walls get the same square detail.
MOD 1172 is listed on page 16 of the UNIKIM 2024 catalogue in three sizes for slot tube Ø42.4, Ø48.3 and Ø60.3 mm. It is part of the Slot Tube Handrail System – all parts.
UNIKIM makes it in its own factory in Ningbo, China. Choose AISI 304 for dry indoor areas and AISI 316 for humid, pool and coastal locations – see 304 vs 316 stainless steel.
Specifications
| Model | MOD 1172 (catalogue p. 16) |
| Type | Wall end fitting (square block, mirrored) |
| Tube sizes | Ø42.4 × 1.5, Ø48.3 × 1.5 and Ø60.3 × 1.5 mm |
| Block | 37 × 30 mm, 11 mm offset (drawing) |
| Material | AISI 304 stainless steel (A2), brushed (S); AISI 316 (A4) on request |
Versions and article numbers
| Art. No. (AISI 304, brushed) | Fits |
|---|---|
| A2.1172.42.S | Slot tube Ø42.4 × 1.5 mm |
| A2.1172.48.S | Slot tube Ø48.3 × 1.5 mm |
| A2.1172.60.S | Slot tube Ø60.3 × 1.5 mm |
For AISI 316 replace A2 with A4.
Applications
Handrails between two walls on stairs, corridors and balconies; projects with square wall details.
Installation notes
- Cut the slot tube square and deburr it; push the fitting in and fix it as shown in the installation guide (glue or screws).
- Order the fitting for the same tube size as your slot tube: Ø42.4, Ø48.3 or Ø60.3 mm.
- Fit the Slot Tube Rubber Strip (MOD 0842 / 0848 / 0860) for your glass before placing the tube on the glass.
MOD 1172 or MOD 1171?
Use MOD 1172 and the Slot Tube Wall End Fitting (MOD 1171) as a pair for left and right ends.
Why order from UNIKIM
We manufacture railing hardware in our own factory in Ningbo and supply distributors, contractors and fabricators worldwide. Mixed orders of spigots, slot tube, fittings and rubber can be shipped together, with OEM packing on request. Browse all slot tube handrail parts.
Related products
- Slot Tube Wall End Fitting (MOD 1171)
- Slot Tube Wall Flange (MOD 1140)
- Slot Tube End Cap (MOD 1100)
- Slot Tube Handrail System – all parts
FAQ
What is a slot tube wall bracket?
A fitting that fixes the end of the slot tube handrail to a wall. MOD 1172 is the square, mirrored version of MOD 1171.
How big is it?
The block is 37 × 30 mm with an 11 mm offset.
Which sizes are available?
For Ø42.4, Ø48.3 and Ø60.3 mm tube.
Do I need both 1171 and 1172?
Usually yes, one for each end of a run between two walls.
Need a price? Request a quotation with the model number, size, quantity and finish.
